COPPER


The "Godfather" of Red Metals

For over 36 years New West Metals has offered to our customers a complete range of Copper Alloys. Below, you will find and overview of the vast copper product lines that are available from your "One Stop Shopping Center" New West Metals Inc.

Copper is widely viewed as a barometer for the health of the overall global economy since it is used in electronics, homes and infrastructure. Copper Alloys have excellent electrical and thermal conductivity.

New West Metals Inc offers a complete product line of flat, Round, Square, Sheet, Plate, Coil, Strip, Pipe, Tube, Wire, Fasteners, Fittings, Shim, Bus Bar, Bare or Tin Plated, Alloys C110, C101, C102, Beryllium Copper C172-173, Oxygen Free Copper (OFHC), Cupro Nickel Tube, Rod and Sheet.

COPPER ALLOYS

C11000 Electrolytic Tough Pitch Copper (ETP)

The most common and readily available Copper Alloy. ETP- Electrolytic Tough Pitch Copper is used for production of wire, rod, plate, sheet and strip. It is the choice for bus connections, switch & panel boards, circuit breakers and power feed systems because of its high electrical conductivity, case of soft of silver soldering.

This alloy is also used in the distillery kettle vats, pressure vessels and other such like process equipment. Its resistance to corrosion enables longevity.


Roofing Copper C11000 Cold Rolled

Copper had been used in building construction for centuries. NWM offers a complete size range of C11000 Cold Rolled Roofing Sheet. Copper sheet has been used in the construction roofing industry for over 100 years. Copper has a unique decorative appearance with its aesthetically pleasing green patina hue that forms over time. Copper roofs have a very economical appeal as its longevity will outperform basic construction material.


C10100 Oxygen Free Electronic Grade Copper



C10100- Oxygen Free Electronic Grade Copper is the highest grade of copper at 99.99% purity. A commercially pure high conductivity copper which has been produced in such manner as to contain no oxide or residual deoxidants. It has a very high resistance to hydrogen embrittlement.


C10200 Oxygen Free High Conductivity Copper


C10200 Oxygen Free High Conductivity Copper combines most of the advantages of ETP Copper and Deoxidized Copper. C10200 has a high thermal electrical conductivity which is good for severe deep drawing, spinning and close radius binding. It is used in electronic tubes or similar applications because it makes a perfect seal to glass. C10200 is excellent for electrical purposes as its conductivity is much higher than that of what deoxided can offer. Oxygen - Free Copper is often specified.


C- Phosphorus Deoxidized Copper


This type of copper differs from ETP Copper C1100 in that it has lower electrical and thermal conductivity, but it forms and bends more readily in more difficult applications. It's used in applications requiring hot working, annealing soldering, brazing or welding operations in which residual phosphorus prevents the absorption of oxygen by the copper. This type of copper is recommended in sheets or plates that are to be welded.

C- Phosphorus Deoxidized Copper is widely used in pipes and tubes for plumbing, gas, oil lines, refrigeration, condensers, pulp & paper lines, brewery & distillery tubes, brew kettles, vats and industrial tanks.


Copper Tempers

060- Soft Annealed

H00- Cold Rolled Equals 1/8 hard

H01- Cold Rolled Equals 1/4 hard

H02- Cold Rolled Equals 1/2 hard

H04- Hard

H80- Hard Draw

C10100 OFHC, C11000 ETP, C14500 Tellurium, C172-17300 Beryllium, C18200 Chrome, C79200 Nickel Silver

Shapes and Forms of Copper

Round - Square- Hexagon

C10100 OFHC, C11000 ETP, C14500 Tellurium

Rectangle

  Copper sheet provided by New West Metals  Fabricated by Elite Metal Products - Winnipeg MB

Copper sheet provided by New West Metals
Fabricated by Elite Metal Products - Winnipeg MB

C10100 OFHC, C11000 ETP S

heet-Plate

C11000 ETP, C17200 Beryllium

Coil

C10100- 102 OFHC, C0300XLP, C12200 DHP

Tubing

C11000 ETP, C10100- 102 OFHC, C12200 DHP

Wire

C11000ETP

Foil

C12200

Pipe

C10100- 102 OFHC, C11000ETP, SCH 40 & 80

Custom Shapes


Beryllium Copper


Available in Bar and Strip-- C17200, C17300, C17500, C17510

Beryllium Copper is the strongest and best spring material among all copper alloys for application in high temperature, high corrosive and high electrical current environment. As well it has properties of high conductivity, elasticity and tensile strength. An aged harden material Beryllium Copper is the best choice for miser switch connector, terminal relay and high precision spring parts.

Typical Applications:Beryllium Copper is used for is in plastic injection molding and metal die castings, bushings, bearings for the aerospace industry and in the oilfields for drilling collars, instrument housings and springs.


Copper Nickel Products


Copper Nickel is extensively used in corrosion and bio-fuel resistant application, such as in components for desalination plants, seawater intakes, piping systems, heat exchangers and condensers. The material is particularly adaptable for forming and or welding applications.


Copper Nickel Rod

C70600 C71500

Copper Nickel Sheet

C70600 C71500


Copper Nickel Tubing

90-10 Seamless C70600 70-30 Seamless C71500 90-10 Welded C70600

70-30 Welded C71500 90-10 Condenser C70600 70-30 Condenser C71500

Arsenical Admiralty Condenser C44300

Copper Nickel is available in Round Bar, Sheet, Plate, Tube, Pipe, Fittings and Flanges


Copper Pipe

  • Copper Bus Pipe - Regular and Sch 40

  • Copper Bus Pipe, Extra Strong Sch 80

Copper Tubing

  • Soft copper refrigeration tubing in coils, sealed ends

  • Soft copper tubing in coils, non-refrigeration sizes, Open ends

  • Hard Drawn Copper tubing , straight lengths

  • Plastic Coated copper Instrument tubing

  • Drawn seamless copper tubing

  • Copper water Tubing

  • Tube types K, L & M

Copper Rod & Bar

  • Round Copper Rod

  • Square Copper Bar

  • Rectangular Copper Bus Bar, Round Edge

Copper Wire

  • Hard and soft drawn Copper wire on Spools

Copper Sheet and Plate

COPPER SHEET.jpg
  • Sheet copper- roofing

  • Patterned copper

  • Rolled Copper

    • Standard roofing

  • Copper sheet and plate OFHC10100/10200 Copper sheet and plate

  • Copper sheet and plate ETP11000 Copper Sheet and Plate

Copper Fasteners

  • Slating nails

  • Wire nails

  • Copper nails

  • Bronze Ring Nails

Copper Fittings




“LET US BE OF SERVICE TO YOU”

NEW WEST METALS INC.
SERVICES THE FOLLOWING INDUSTRIES WITH COPPER

Screen Shot 2018-11-08 at 9.45.43 PM.png
  • AUTOMOTIVE

  • ELECTRICAL

  • ARCHITECTURAL

  • MARINE

  • FLUID POWER

  • PLUMBING

  • BUILDING

YOUR CHOICE FOR ALL COPPER ALLOYS

Our turnaround time for non stock items is minimal. Cut to size!! No Minimum Orders!!
FOB YOUR DOOR!!
