BRONZE

New West Metals Inc. Offers a complete range of stocked Bronze Alloys. New West Metals currently offers to their customers the largest inventory in Bronze Alloys in Western Canada. Below you will find and overview of the vast product lines that are available from your "One Stop Shopping Center" New West Metals Inc.

The two most common Bronze Alloys in the industry today are available in tubes, solids and rectangles.


1) 932000 SAE 660 Bronze

"Is the workhorse alloy" the most popular bronze alloy we offer at NWM. It is a general purpose bearing alloy with a wide range of applicability. This alloy utilizes a combination of tin and zinc for cost effective strengthening. Typical uses are general utility bearings & bushing, washers, cylinder liners and linings for hydraulic presses.

2) C95400 9C Aluminum Bronze

Aluminum Bronze is the highest strength standard copper based alloy and the most popular of the aluminum bronze group. It offers high yield strength, exceptional toughness, good resistance to wear, fatigue and deformation under shock and overload. Typical uses are bearing & bushings, spurs, gears, worm wheels, wear strips and valve components.


Bronze Alloys


Leaded Tin Bronze

C92200
C92300
C92700
C92800
C93200

Leaded Red Brass

C8400

Manganese Bronze

C86300
C67300

Aluminum Bronze


C95400 C95500 C95900 C62500

High Tin Bronze

C90300 C90500 C90700 C90800 C90810 C91000 C91100 C91300 C91600 C91700

High Lead Tin Bronze

C93400 C93500 C93600 C93700 C93800 C93900 C94000 C94100 C94300

Phosphor Bronze

C51000 C54400 B-2 FREE CUTTING

Silicon Bronze

C63600 C64200 C64210 EVERDUR 6421 C64700 NICKEL SILICON BRONZE

C65100 LOW SILICON C65300 SILICON BRONZE

C65500 HIGH SILICON BRONZE AC65600 EVERDUR 656

C65610 SILICON BRONZE C65620 SILICON BRONZE

C66100 LEADED SILICON BRONZE

Nickel Aluminum Bronze

AMS 4640 AMS 4880 AMS 4881 AMS 4590

SAE 841 OIL IMPREGNATED BRONZE "OILITE"


SAE 863 POWDERED METAL BRONZE

C89835 LEAD FREE BEARING BRONZE

C22000 COMMERCIAL BRONZE

C38500 ARCHITECTURAL BRONZE


Specifications

ASTM B505 CONTINUOUS CAST C863, C932, C954, C89835

ASTM B271 CENTRIFUGAL CAST C932, C936,C954

ASTM B584 SAND CASTING C932, C936, C954

ASTM B438-70 SINTERED C841

ASTM B439-70 SINTERED C863

ASTME B150 & AMS4640 EXTRUDED COLD DRAWN C630

SAE J463 EXTRUDED COLD DRAWN C673

Click the link to see our flyer: Bronze Alloys




“LET US BE OF SERVICE TO YOU”

NEW WEST METALS INC.
SERVICES THE FOLLOWING INDUSTRIES WITH BRONZE ALLOYS

Screen Shot 2018-11-08 at 9.45.43 PM.png
  • MINING

  • AGRICULTURE

  • PULP & PAPER

  • MANUFACTURING

  • OIL & GAS

  • MARINE

YOUR CHOICE FOR ALL BRONZE ALLOYS

Our turnaround time for non stock items is minimal. Cut to size!! No Minimum Orders!!
FOB YOUR DOOR!!
